产品名称及型号 Product name and model | EQ2160B |
驱动方式 Drive mode | 4×4 |
|
尺寸参数 Size parameters |
外形尺寸 长×宽×高(mm) Overall dimensions: length×width×height(mm) | 7130×2500×3300 | |
|
货箱内部尺寸 长×宽×高(mm) Container inside dimension: length×width×height(mm) | 4600×2294×550 | ||
|
轴距（mm） Wheel base（mm） | 4200 | ||
|
轮距(前/后)(mm) Tread(Front/Rear)(mm) | 2038/1869 | ||
|
前悬/后悬(mm) Front overhang /Rear overhang (mm) | 1430/1500 | ||
|
接近角/离去角(º) Approach angle /Departure angle (º) | 30/25 | ||
|
最小离地间隙(mm) Minimum ground clearance(mm) | 320 | ||
|
油箱容积(L) Oil tank capacity (L) | 200 | ||
|
性能参数 Performance parameters |
最高车速(km/h) Maximum speed (km/h) | 80 | |
|
最小转弯直径(m) Minimum turning diameter(m) | 17.5 | ||
|
最大爬坡度(%) Maximum gradability (%) | 40 | ||
|
质量参数 Mass parameter |
整备质量(kg) Unladen mass (kg) | 7585 | |
|
额定载质量(kg) Rated load mass (kg) | 8285 | ||
|
总质量(kg) Gross mass(kg) | 16000 | ||
|
发动机 Engine |
型式及类别 Model and variety |
直列增压中冷六缸水冷柴油机 Straight inter-cooled 6-cylinder water-cooled diesel engine | |
|
型号 Model | ISB210 40 | ||
|
生产企业 Manufacturer |
东风康明斯公司 Dongfeng Cummmins Co., Ltd. | ||
|
排量（ml） Discharge capacity（ml） | 5900 | ||
|
燃料种类 Fuel type |
柴油 Diesel | ||
|
额定功率/转速(kW/r/min) Rated power /speed (kW/r/min) | 155/2500 | ||
|
最大扭矩/转速(N.m/r/min) Maximum torque /speed (N.m/r/min) | 750/1200-1700 | ||
|
缸径×行程(mm×mm) Cylinder diameter×travel route(mm×mm) | 102×120 | ||
|
压缩比 Compression ratio | 17.3:1 | ||
|
离合器 Clutch |
型号及型式 Model and type |
单片干式膜片离合器 Dry single disc clutch | |
|
操纵方式 Control mode |
液压远距离操纵 Hydraulic remote control | ||
|
磨擦片直径(mm) Wearing piece diameter (mm) | φ395 | ||
|
变速箱 Transmission |
操纵方式 Control mode |
机械式 Mechanical control | |
|
前进档位数 Forwardgear digit | 8 | ||
|
速比 Speed ratio | Ⅰ8.12 Ⅱ6.08 Ⅲ4.47 Ⅳ3.31 Ⅴ2.46 Ⅵ1.84 Ⅶ1.35 Ⅷ1.00 RL8.12 RH2.46 | ||
|
分动箱 Auxiliary box |
速比 Speed ratio | 1．00 1.5 | |
|
车架 Frame |
结构型式 Structure type |
铆接结构 Riveted structure | |
|
纵梁断面尺寸(mm) Longitudinal beam cross dimensions (mm) |
280×80×（8＋4） | ||
|
电器 Electrical appliances |
电器线路电压(V) Electrical appliance line voltage(V) |
24 | |
|
数量 Accumulator modelquantity |
140A.h 两个 140A.h 2 pieces | ||
|
发电机 电压/电流 Generator Voltage/Current | 28V,70A | ||
|
车身 Body |
型式 Type |
可翻转式,卧铺加宽新内饰 Convertible, widened sleeper with new decoration | |
|
生产企业 Manufacturer |
东风商用车公司 Dongfeng Commercial Vehicle Company | ||
|
人 Number of passengers in the cab (number) |
2 | ||
|
底盘 Chassis |
型号类别 Modeland type | EQ2160B | |
|
轴数及轮胎 Number of axles and tire |
轴数 Number of axles | 2 | |
|
轮辋型号 Wheel felloe model | 7.5v-20 | ||
|
轮胎规格及轮胎数 Tire specification and tire number | 10.00R20 6+1 | ||
|
转向型式 Steering type |
动力转向 Power steering | ||
|
前桥 Frontgear |
型式 Type |
铸造桥壳带轮边减速 Cast rigid axle housing with hub reduction gear | |
|
额定载荷（t) Rated load（t) |
6T级 Grade6T | ||
|
后桥 Reargear |
型式 Type |
铸造桥壳带轮边减速 Cast rigid axle housing with hub reduction gear | |
|
主减速比 Major reduction ratio | 5.921 | ||
|
额定载荷（t) Rated load（t) |
级 Grade 10T | ||
|
制动系统 Braking system |
行车制动型式 Auto brake type |
双回路气制动 2-circuit air braking | |
|
行车制动助力型式 Auto brake boost type |
气压伺服助力 Pneumatic servo boost | ||
|
制动力调节型式 Brake power adjustment type |
手动 Manual | ||
|
制动器型式 Brake type |
鼓式 Drum type | ||
|
驻车制动型式 Parking brake type |
弹簧制动 Spring brake | ||
|
应急制动型式 Emergency brake type |
弹簧制动 Spring brake | ||
|
悬架 Overhang frame |
前 Front |
型式 Type |
钢板弹簧 Road spring |
|
钢板弹簧片数 Number of road springs | 8 | ||
|
后 Rear |
型式 Type |
钢板弹簧 Road spring | |
|
钢板弹簧片数 Number of road springs | 10+8 | ||
<
<
<
<
